E-Line UKS-UKD-UKN-UKFE Cable Trays

Perforated Cable Tray & Pre-Galvanised Cable Tray IEC

The E-LINE UKS range of pre-galvanized snap-on are produced in heavy service type with TSE and ISO 10143 standard. They are produced in 3 m lengths as standard. It is designed to carry cable installations in internal environments of facilities and buildings.

GENERAL INFORMATION
DOCUMENTS
BIM
GALLERY
VIDEOS

E-LINE UKN snap-on are produced as pre-galvanized. They are lighter compared to heavy service type snap-on thanks to its normal service structure and they offer more economical solutions.

E-LINE UKFE series snap-on have the same carrying capacity as thicker snap-on as a result of giving shape to the sheet steel. Produced as pre-galvanized, these snap-on can be used internally in the buildings.

PRODUCTS	MATERIAL	FINISHES	THICKNESS OF COATED	WIDTH(mm)	SIDE HEIGHT (mm)	THICKNESS (mm)	DUTY TYPE	CORROSSION CATEGORY
UKS	High-quality iron-based sheet metal	Pregalvanized TSE EN ISO 10143 TSE EN ISO 10346	10 - 14µm	50 / 100 / 150 / 200 / 250 / 300 / 400 / 500 / 600	40 / 60	0,8 / 1 / 1,2 / 1,5	Medium/Heavy	C1 C2
UKD	High-quality iron-based sheet metal	Pregalvanized TSE EN ISO 10143 TSE EN ISO 10346	10 - 14µm	50 / 100 / 200 / 300 / 400 / 500 / 600	40 / 60	0,8 / 1 / 1,2 / 1,5 / 2	Medium/Heavy	C1 C2
UKN	High-quality iron-based sheet metal	Pregalvanized TSE EN ISO 10143 TSE EN ISO 10346	10 - 14µm	50 / 100 / 200 / 300 / 400 / 500 / 600	40 / 60	0,8 / 1 / 1,2 / 1,5	Medium/Heavy	C1 C2
UKFE	High-quality iron-based sheet metal	Pregalvanized TSE EN ISO 10143 TSE EN ISO 10346	10 - 14µm	100 / 200 / 300 / 400 / 500 / 600	40 / 60	0,7 / 0,9	Normal	C1 C2

Flexible Module

Flexible module which is specially designed and manufactured for our product range of cable trays, has a bendability up to 90 ° which allows the Cable Trays to be installed quickly and easily at the desired angle.

Technical Features

UKS Cable Tray

In heavy service type
In standard 40 mm and 60 mm channel heights (Produced in special 50-75-100 mm heights)
Allows connection of various accessories with 20.5-diameter holes at the centre of the channel (Allows rapid connection of devices such as illumination panel, fire detector, etc.)

3000-4000-5000-6000 mm lengths can also be produced.
Wide range of accessories
Fire resistance certificates (E30-E60-E90)
Painted galvanize versions on request (Epoxy, epoxy Polyester, Polyester)

UKFE Cable Tray

In 100-200-300 mm widths it is produced with 0.7 mm thickness and, between 400-500-600 mm widths, with 0.9 mm thickness.
It is designed to carry approximately the same load as products with conventional thicknesses thanks to the special forms on the snap-on and materials used
Compatible with UKS modules
Fire resistance certificates (E30-E60-E90)
