KCA OG Cable Ladder Systems

Extra Heavy Duty Cable Ladder NEMA

E-Line KCA OG has earned a reputation as the industry standard for cable support systems all over the world. The E-Line KCA OG (Cable Ladder System) has a unique combination of very high strength, and durability, and a lightweight design.
E-Line KCA OG Cable Ladder range has been engineered to have the highest ultimate load bearing strength in its class, a very high resistance to impact and environmental forces, while also minimizing weight. Our structural design maximizes the physical properties of the steel. Project Engineers for large offshore, modular, marine and other projects now have a cable support solution that can give them the strength they need over long spans, while also meeting project weight requirements.

GENERAL INFORMATION
DOCUMENTS
BIM
GALLERY
VIDEOS

Usage Features

Tested according to IEC 61437 standard and certified by DEKRA.
Tested according to NEMA VE-1 standard and certified by DEKRA.

H150 mm cable ladders have a carrying capacity of NEMA 20C.
H100 mm cable ladders have a carrying capacity of NEMA 12C.

Considering industrial plant projects such as petro-chemistry, it meets the following specifications:

Since the cable tray is produced in 6 meters in a single piece, it can be hung at a support range of 6 meters.
Tested and certified according to NEMA VE-1. Has a carrying capacity class of NEMA 20C.
Tested and certified according to IEC 61537.
Has maximum cable carrying capacity with its extra heavy-duty structure.
High quality hot-dip galvanized, hot-dip galvanized using high silicon steel, produced from 316L quality stainless raw material.
High production capacity (6 meters/minute)
Fast due dates and shipping times
Customizable production solutions for different requests
KCA Solutions with all the features listed above can be manufactured with the KCA OG series cable tray/ cable ladder systems.

Technical Features

KCA OG is designed to be used as cable transport systems in petro-chemical, power plants, heavy industrial plants.

Has high load carrying capacity thanks to its specially designed side walls.

Steel side walls are reinforced with feeder lines.

Standard length: 3 – 6 m

Since the cable tray is produced in 6 meters in a single piece, it can be hung at a support range of 6 meters. Thus, the number of support materials to be used is reduced.

Tested under harsh conditions.

According to DIN4102-12 standard, it was tested at a temperature of 1000 degrees for 90 minutes It has successfully passed the -70 C degree test.

Successfully tested at -70°C.
